Adjustable essential wooden terrace pedestal 80/140 mm - ESSENTIEL range - Jouplast

JOU-IH080140LF40000
Jouplast

Joist pedestal 80/140 mm. Adjustment to the millimeter, poses any support and without fixing. Simplified land preparation. Allows the installation of a raised wood or composite deck. compliant with DTU 43.1 and 51.4. Resistant to frost, UV, acid and basic products. Supports up to 1 ton of load. Made in France.

More details


Orders shipped within 24/48 hours



Best prices



Pay in 3 or 4 installments with Oney

€2.30
Tax included
Available stock
45 Items
Packaging
Quantity

Calculate quantities
You might also like
Description
Plot terrasse bois Jouplast 80/140 et ses spécificités techniques

Adjustable terrace pedestal from 80 to 140 mm for wooden terrace, Jouplast

The wooden terrace pedestal is designed to create the foundations of wooden or composite terraces. This raised support for joists is adjustable in height from 80 to 140 mm to adapt perfectly to your wooden terrace project on pedestals. These Jouplast pedestals make it easier for you to level your terrace and install your terrace on pedestals quickly and easily, without earthworks or structural work.

The advantages 80/140 mm wooden terrace pedestals Jouplast

  • Quick and easy to install
  • Manual and precise height adjustment thanks to the green nut
  • Frost and UV resistant
  • Allows air to circulate under the structure
  • Allows the passage of cables and pipes
  • Withstands more than a ton of load
  • Complies with DTU 51.4 and 43.1

Advice for laying a terrace on a wooden or composite pedestal

  • To install your wooden terrace on Essential pedestals, make sure that the ground is stabilized or that you have an existing concrete paving
  • Jouplast wooden terrace pedestals are designed for pedestrian use only.
  • The foundations of the wood or composite terrace must be made with natural wood or aluminum joists and not composite

The steps for laying a wooden terrace on pedestals

1/ Ground preparation

To build your terrace with wooden boards or composite pedestals, there is only one condition: that your ground is stabilized. The 208 mm circular base provides optimal support for the foundations of your wooden terrace on pedestals.

For the stabilization of your ground, one step is mandatory: the preparation of the ground! It guarantees the maintenance of the structure of your terrace. However, there is no need to pour a concrete paving! Yes, preparing the ground is quick and inexpensive with the pedestal terrace solution.


Here is what you need to prepare the ground:

  • A cord
  • Stakes
  • A spirit level
  • A shovel
  • A tape measure
  • A mason's box screed
  • A geotextile film
  • Gravel


4 steps are enough to prepare your ground to accommodate a wooden terrace on adjustable pedestals :

  1. Dig the ground for 15 cm;
  2. Place a geotextile felt there to eradicate the growth of weeds;
  3. Fill the hole with a 15 cm layer of gravel;
  4. Compact and make sure everything is level.

2/ Lay the pedestals, joists and decking boards

Laying a wooden terrace on Jouplast 80/140 mm pedestals is extremely simple to carry out since all you have to do is lay them on the ground without any fixings. Indeed, 4 construction steps are enough to benefit from solid and durable foundations:

  1. Determine the location of the studs and their spacing. Once done, place the pedestals on the ground and adjust the height using the nut for an adjustment to the millimeter;
  2. Place the joists on the head of the pedestals: necessarily in natural wood or aluminium;
  3. Screw the joists onto the tab provided for this purpose to ensure excellent support for your wooden deck on pedestal;
  4. Fix the wooden boards on the joists using screws.

Accessories for laying wooden decks on pedestals Jouplast

Technical characteristics

  • Complies with DTU 51.4 and 43.1
  • Load resistance greater than 1 ton
  • Frost and UV resistant
  • Flange diameter: 208 mm
  • Head diameter: 120 mm
  • Adjustable height: 80 to 140 mm
Product Details
JOU-IH080140LF40000
45 Items

Data sheet

Adjustable height
80 to 140 mm
Color
Black
Material
Polypropylene
Guarantee
2 years warranty
Origin
Manufactured in France
Conformity
Compliance with the DTU 43.1 and 51.4
Resistance
Resistant to acidic and basic solutions, atmospheric agents, temperatures between -30°C and +60°C
Load
Resists the test of crushing with a load superior in 1 ton
Brand
Jouplast
Type
Adjustable
Use
Composite slabs
Wooden slab
Qté lot
40
trad_lot
A batch of
SH Code
39259010
Country of Origin
UE
Installation surface
Loose soil
Type of setting
Manual
Decking pedestal
Wood
Height
From 8 to 12 cm
From 12 to 15 cm

Specific References

EAN13
7061285112041
Attachments
Download
FT-HL-80140-FR

FT-HL-80140-FR_en

Download (1.07MB)
FT_PLOT HL_FR_2112

FT_PLOT HL_FR_2112_en

Download (879.26KB)
